Siemens SIMATIC NET Reference Manual

VHT
(1)
MCS in‐
dex
(2)
Spa‐
tial
strea
ms
Transmission speed in Mbps
20 MHz channel 40 MHz channel 80 MHz channel 160 MHz channel
Guard interval Guard interval Guard interval Guard interval
800 ns 400 ns 800 ns 400 ns 800 ns 400 ns 800 ns 400 ns
3 1 26,0 28,9 54,0 60,0 117,0 130,0 234 260
4 1 39,0 43,3 81,0 90,0 175,5 195,0 351 390
5 1 52,0 57,8 108,0 120,0 234,0 260,0 468 520
6 1 58,5 65,0 121,5 135,0 263,3 292,5 526,5 585
7 1 65,0 72,2 135,0 150,0 292,5 325,0 585 650
8 1 78,0 86,7 162,0 180,0 351,0 390,0 702 780
9 1 - - 180,0 200,0 390,0 433,3 780 866,7
0 2 13,0 14,4 27,0 30,0 58,5 65,0 117 130
1 2 26,0 28,9 54,0 60,0 117,0 130,0 234 260
2 2 39,0 43,3 81,0 90,0 175,5 195,0 351 390
3 2 52,0 57,8 108,0 120,0 234,0 260,0 468 520
4 2 78,0 86,7 162,0 180,0 351,0 390,0 702 780
5 2 104,0 115,6 216,0 240,0 468,0 520,0 936 1040
6 2 117,0 130,0 243,0 270,0 526,5 585,0 1053 1170
7 2 130,0 144,4 270,0 300,0 585,0 650,0 1170 1300
8 2 156,0 173,3 324,0 360,0 702,0 780,0 1404 1560
9 2 - - 360,0 400,0 780,0 866,7 1560 1733,3
0 3 19,5 21,7 40,5 45,0 87,8 97,5 175,5 195
1 3 39,0 43,3 81,0 90,0 175,5 195,0 351 390
2 3 58,5 65,0 121,5 135,0 263,3 292,5 526,5 585
3 3 78,0 86,7 162,0 180,0 351,0 390,0 702 780
4 3 117,0 130,7 243,0 270,0 526,5 585,0 1053 1170
5 3 156,0 173,3 324,0 360,0 702,0 780,0 1404 1560
6 3 175,5 195,0 364,5 405,0 - - 1579,5 1755
7 3 195,0 216,7 405,0 450,0 877,5 975,0 1755 1950
8 3 234,0 260,0 486,0 540,0 1053,0 1170,0 2106 2340
9 3 260,0 288,9 540,0 600,0 1170,0 1300,0 - -
0 4 26,0 28,9 54,0 60,0 117,0 130,0 234 260
1 4 52,0 57,8 108,0 120,0 234,0 260,0 468 520
2 4 78,0 86,7 162,0 180,0 351,0 390,0 702 780
3 4 104,0 115,6 216,0 240,0 468,0 520,0 936 1040
4 4 156,0 173,3 324,0 360,0 702,0 780,0 1404 1560
5 4 208,0 231,1 432,0 480,0 936,0 1040,0 1872 2080
6 4 234,0 260,0 486,0 540,0 1053,0 1170,0 2106 2340
7 4 260,0 288,9 540,0 600,0 1170,0 1300,0 2340 2600
8 4 312,0 346,7 648,0 720,0 1404,0 1560,0 2808 3120
9 4 - - 720,0 800,0 1560,0 1733,3 3120 3466,7
(1)
Very High Throughput data 󹪝eld
(2)
Modulation and Coding Scheme index
Data transmission speed
2.3 IEEE 802.11ac
Performance data SCALANCE W700 802.11ax
Reference Manual, 04/2021, C79000-G8976-C620-01 11
