Technical specifications
SIMATIC RF1000
58 Operating Instructions, 11/2019, C79000-G8976-C432-06
6GT2831-6xA50
Permitted ambient conditions
Ambient temperature
• During operation • -25 ... +55 °C
• During transportation and storage • -25 ... +55 °C
Minimum distance between two readers 15 cm
Degree of protection to EN 60529 In installed state:
front IP65;
rear IP20
Shock-resistant to EN 60721-3-7, Class 7 M2
300 m/s²
Vibration-resistant to EN 60721-3-7, Class 7 M2
50 m/s²
Design, dimensions and weights
Dimensions (W × H × D)
• excl. card holder • 90 × 62 × 23.5 mm
• Incl. card holder • 99 × 62 × 34.6 mm
• Mounting opening • 76 (± 0.3) × 48 (± 0.3) mm
Weight
approx. 120 g
Type of mounting Door installation
• 4 x stud screws (slotted screws) M4 x 20;
Tightening torque ≤ 0.5 Nm
• 4 x Torx screws (EJOT) T10 x 10;
Tightening torque ≤ 1.5 Nm
• Installation wall thickness 2-7 mm
Cable length reader ↔ communications module
1.8 m USB connecting cable
Display elements
• LED, 3 colors
• Acoustic signal
1)
Approvals CE, FCC, IC
ATEX
2)
MTBF
28 years
1)
Only in conjunction with the SIMATIC RF1040R reader as of product version "AS: A" and SIMATIC
RF1070R as of product version "AS: B".
2)
Only in conjunction with the SIMATIC RF1060R readers as of product version "AS: B" and
SIMATIC RF1070R as of product version "AS: C".
