Siemens Simatic S7-1500

Product overview
2.3 Properties
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
Manual, 09/2016, A5E35306440-AB
27
2.3.2
Properties of the analog on-board I/O
View
The following figure shows the analog on-board I/O (X10) of the CPU 1512C-1 PN.
Figure 2-2 Analog on-board I/O
