Technology functions
3.2 Pulse generators
CPU 1512C-1 PN (6ES7512-1CK00-0AB0)
68 Manual, 09/2016, A5E35306440-AB
Table 3- 7 Status feedback
STS_READY The channel is correctly configured, is operating and
supplying valid data.
0: Not ready to run
STS_SW_ENABLE Current status of the software enable 0: SW_ENABLE is not active
1: SW_ENABLE detected
STS_LD_SLOT Acknowledgment bit for each action of the SLOT in the
SLOT mode for individual updating (for a description of
the acknowledgment bit, refer to the section Handling
the SLOT parameter (control interface) (Page 64)).
Each switching of this bit represents
a successful LD_SLOT action.
STS_ENABLE
The output sequence is active.
(STS_ENABLE always depends on the status of the
software enable STS_SW_ENABLE ab)
0: No output sequence running
1: Output sequence running
STS_DQA State of the pulse output (DQA) 0: Pulse output is not active
1: Pulse output is active
ERR_PWR No supply voltage L+ 0: No error
ERR_LD Error during loading of a parameter value in the
operating mode for individual updating
0: No error
ERR_OUT_VAL The value in OUTPUT_VALUE is invalid 0: No error
ERR_SLOT_VAL The value in SLOT is invalid, where MODE_SLOT
= 1 (permanent updating)
0: No error
