Siemens Simatic S7-1500R - Connecting; Assignment of MAC Addresses Using the Example of a Single CPU

Connecting
3.1 Terminal assignment
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Equipment Manual, 11/2019, A5E42009914-AB
27
The table below shows how the MAC addresses are assigned.
Table 3- 2 Assignment of MAC addresses using the example of a single CPU
Assignment
Labeling
MAC address 1
PROFINET interface X1
(visible in STEP 7 for accessible devices)
• Front printed
• Right-side printed
(start of number range)
MAC address 2
Port X1 P1 R (required for LLDP, for example)
---
MAC address 3
Port X1 P2 R (required for LLDP, for example)
---
MAC address 4
PROFINET interface X2
(visible in STEP 7 for accessible devices)
• Front printed
MAC address 5
Port X2 P1 (required for LLDP, for example)
• Right-side printed
(end of number range)
