Technical specifications
CPU 1515R-2 PN (6ES7515-2RM00-0AB0)
Equipment Manual, 11/2019, A5E42009914-AB
35
Article number
6ES7515-2RM00-0AB0
Work memory
• integrated (for program)
500 kbyte
• integrated (for data)
3 Mbyte
Load memory
• Plug-in (SIMATIC Memory Card), max.
32 Gbyte
Backup
• maintenance-free
Yes
CPU processing times
for bit operations, typ.
60 ns
for word operations, typ.
72 ns
for fixed point arithmetic, typ.
96 ns
for floating point arithmetic, typ.
384 ns
CPU-blocks
Number of elements (total)
6 000; Blocks (OB, FB, FC, DB) and UDTs
DB
• Number range
Number range: 1 to 59 999
• Size, max.
3 Mbyte; For non-optimized block accesses, the
max. size of the DB is 64 KB
FB
• Number range
0 ... 65 535
• Size, max.
500 kbyte
FC
• Number range
0 ... 65 535
• Size, max.
500 kbyte
OB
• Size, max.
500 kbyte
• Number of free cycle OBs
100
• Number of time alarm OBs
20
• Number of delay alarm OBs
20
• Number of cyclic interrupt OBs
20
• Number of process alarm OBs
50
• Number of startup OBs
100
• Number of asynchronous error OBs
4
• Number of synchronous error OBs
2
• Number of diagnostic alarm OBs
1
Nesting depth
• per priority class
24
