Siemens SIMATIC S7-1500T Reference Manual

A5E33284667-AF Page 25
Extended instructions
Basic instructions
Communication
Technology
S7-300
S7-400
S7-1200 S7-1500
Description LAD/FBD
STL
(not S7-1200)
SCL
✔ ✔ ✔
Unscale the
floating-point number into physical
units between a low limit and a high limit and
convert it into an integer (unscaling).
UNSCALE
Program control operations
✔ ✔ ✔ ✔
Branch conditionally
JC
IF… THEN…
ELSE…
✔ ✔ ✔ ✔
Branch conditionally multiple times
IF… THEN…
ELSIF…
✔
✔
✔
✔
Branch to a list element
SPL
CASE… OF…
✔ ✔ ✔ ✔
Run in counting loop
FOR… TO…
DO…
✔ ✔ ✔ ✔
Run in counting loop with step width
FOR… TO…
BY… DO…
✔ ✔ ✔ ✔
Run if condition is met, the CPU checks the
condition at the start of the loop
JC
WHILE… DO…
✔ ✔ ✔ ✔
Run if condition is not met.
The CPU checks the condition at the end of the
loop, i.e. the CPU runs the loop at least once.
LOOP
REPEAT…
UNTIL…
