Siemens SIMATIC Equipment Manual

Technical specifications
I/O device digital inputs DI 16x24VDC M12-L 8xM12 (6ES7141-6BH00-0BB0)
Equipment Manual, 06/2021, A5E46570510-AB
31
Article number
6ES7141-6BH00-0BB0
Encoder supply
24 V encoder supply
• Short-circuit protection
Yes; Group-by-group for 2 channels, electronic
• Output current, max.
100 mA; per output
Power loss
Power loss, typ.
8.1 W
Address area
Address space per module
• Inputs
2 byte; + 2 bytes for QI information
Hardware configuration
Submodules
• Number of configurable submodules, max.
2
Digital inputs
Number of digital inputs
16
Digital inputs, parameterizable
Yes
Source/sink input
P-reading
Input characteristic curve in accordance with IEC
61131, type 3
Yes
Number of simultaneously controllable inputs
all mounting positions
–
up to 60 °C, max.
16
Input voltage
• Rated value (DC)
24 V
• for signal "0"
-30 to +5 V
• for signal "1"
+11 to +30V
Input current
• for signal "1", typ.
2.4 mA
Input delay (for rated value of input voltage)
for standard inputs
–
parameterizable
Yes; 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms
Cable length
• unshielded, max.
30 m
Encoder
Connectable encoders
• 2-wire sensor
Yes
–
permissible quiescent current (2-wire sen-
sor), max.
1.5 mA
Interfaces
Number of PROFINET interfaces
1
1. Interface
Interface type
PROFINET with 100 Mbit/s full duplex (100BASE-
TX)
