Description
2.3 Different encoder replacement types
Replacing an encoder for SIMOTICS S-1FK7 G2, S-1FG1 and S-1FT7
Service Manual, 01/2018, A5E34676237B AC
21
Short handling instructions for each replacement option
Replacement version 1
Replacement version 2
Replacement version 3
The operations to be
performed are de-
scribed in the following
Chapters.
How do you replace the defec-
tive encoder? (Page 34)
How do you replace the defec-
tive encoder? (Page 34)
How do you replace the defec-
tive encoder? (Page 34)
Program the encoder (How do
you program an encoder that
has not been loaded with da-
ta? (Page 38))
Result
System ready *)
System ready *)
System ready *)
Other activities Program the encoder later
(How do you program an en-
coder that has not been load-
ed with data? (Page 38))
*) With absolute encoders, the encoder position information must be adjusted to the machine's mechanical system (abs
o-
lute adjustment)
**) Up to the subsequent programming of the electronic t
ype plate, the following message is output: "Component found
without motor data".
