Commissioning (software)

6.4 Configuring a CX32-2

SIMOTION D4x5-2

Commissioning and Hardware Installation Manual, 02/2012

199

CX32-2 topology

The CX32-2 topology displays the DRIVE-CLiQ port required for connection to the

SINAMICS Integrated. The drive objects connected to the CX32-2 are also displayed.

Figure 6-30 CX32-2 topology

Note

Topology errors can result in a download or system power-up not being possible.
