Description
1.2 System components
SIMOTION D4x5-2
22 Commissioning and Hardware Installation Manual, 02/2012
Component Function
SMx sensor modules ... enable acquisition of encoder data from connected motors via
DRIVE-CLiQ.
Motors with DRIVE-CLiQ
interface
... allow simplified commissioning and diagnostics, as the motor
and encoder type are identified automatically.
DMC20/DME20 DRIVE-CLiQ hub … enables the number of DRIVE-CLiQ interfaces to be increased
and the creation of a point-to-point topology.
Note
You can find detailed information about components in the SINAMICS S110/S120 family of
products in the SINAMICS S110/S120 manuals.
It is possible that older DRIVE-CLiQ components can no longer be used with SIMOTION
D4x5-2/CX32-2. You can find detailed information on this in SIMOTION D4x5-2
Commissioning and Hardware Installation Manual at "Migration of D4x5 to D4x5-2" in
Section "Permissible combinations".
Optional components
The functionality of the D4x5-2 control unit can be expanded with the following components:
Table 1- 7 Optional components
Component Function D4x5-2 DP D4x5-2 DP/PN
CBE30-2 Ethernet
communication board
Communication via PROFINET IO with
IRT and PROFINET IO with RT
No Yes
TB30 terminal board Terminal expansion, i.e. additional
analog and digital I/Os
Yes Yes
The components are plugged into the option slot of the control unit.
