Diagnostics
8.1 Diagnostics via LED displays
SIMOTION D4x5-2
352 Commissioning and Hardware Installation Manual, 02/2012
Meaning LED display
RDY RUN STOP SU/PF SF DP DP/MPI PN SY/MT OPT
PROFINET IO interface (CBE30-2, X1400)
No CBE30-2 inserted x x x x x x x x x 0
CBE30-2 runs error-free x x x x x x x x x 1
(green)
Bus error (CBE30-2):
• Failure of a connected IO
device
• At least one of the assigned IO
devices cannot be addressed
• Incorrect or no configuration
x x x x x x x x x 2/1
(red)
Firmware downloaded x x x x x x x x x 2/1
(green)
Firmware download faulty x x x x x x x x x 0.5/1
(red)
1)
The LED state appears only very briefly due to the speed at which the "overall reset" is completed. The module then powers up (the
STOP LED flashes yellow at 2 Hz).
2)
The copying procedure is completed when the SF LED is steady green for at least 10 s.
3)
Both options depend on the LED state when activated via p0124[0] = 1.
4)
The upgrade or downgrade is complete when the SF LED goes out. The device then boots up automatically in the upgraded or
downgraded configuration (SF LED display then depends on the operating mode of the device).
See also
For detailed information on the LED states, see Section LED displays of the PROFINET
interface (Page 354).
Additional references
Further references can be found in the
Upgrading SIMOTION Devices
Operating
Instructions.
