Diagnostics
8.2 Diagnostic data and non-volatile SIMOTION data
SIMOTION D4x5-2
Commissioning and Hardware Installation Manual, 02/2012
365
4. Once the backup is complete, you can release the button and switch off the D4x5-2.
5. Remove the CompactFlash card.
Table 8- 11 LED displays during backup procedure
Status LED displays on the D4x5-2
Backup in progress STOP LED and SU/PF LED flicker yellow
Backup complete RUN LED flickers green
INI file in the CompactFlash card main directory
1. Use a text editor (such as Notepad) to create a file called
simotion.ini
2. Add the following text: DIAG_FILES=1
You must use a text editor and may not use any formatting in the text.
3. Copy the simotion.ini file to the CompactFlash card main directory.
4. Insert the CompactFlash card into the switched-off module.
5. Switch the D4x5-2 on and allow the SIMOTION device to power up.
The diagnostics data and the non-volatile SIMOTION data will be backed up to the data
carrier during power-up, provided that this is still possible and is not prevented by HW
defects, for example.
6. Once the backup is complete, switch off the SIMOTION device.
7. Remove the CompactFlash card.
NOTICE
To suppress startup in diagnostics mode again, you must delete the
simotion.ini
file from
the CompactFlash card.
Table 8- 12 LED displays during backup procedure
Status LED displays on the D4x5-2
Backup in progress STOP LED and SU/PF LED flicker yellow
Backup complete RUN LED flickers green
