6.4 CBE30-2 Ethernet communication board
SIMOTION D4x5-2
112 Manual, 02/2012
6.4.6 Dimension drawing
CBE30-2 representation
The following illustrations show the components in four views.





Figure 6-11 CBE30-2 dimension drawing
6.4.7 Commissioning
Additional references
● SIMOTION D4x5-2 Commissioning and Hardware Installation Manual
●
SIMOTION Communication System Manual
