SIMOTION D4x5-2
Manual, 02/2012
37
Operator control (hardware)
2
2.1 Overview of operator control and display elements
The following figure shows the arrangement of the operator control and display elements of a
SIMOTION D445-2 DP/PN.
2SHUDWRUFRQWURO
DQGGLVSOD\
HOHPHQWV
$UHDSURWHFWHGE\
EODQNLQJFRYHU
Figure 2-1 Position of operator control and display elements (example of SIMOTION D445-2
DP/PN)
