Siemens SIMOTION D445

Interfaces
3.6 Power supply
SIMOTION D4x5-2
Manual, 02/2012
65
Position of power supply interface

0
-XPSHU
3RZHUVXSSO\FRQQHFWRU
Figure 3-7 Position of the power supply interface (example of SIMOTION D445-2 DP/PN)
Note
The power supply terminal strip must be screwed on tightly using a flat-bladed screwdriver.
