Siemens SINAMICS V90 User Manual

Mounting
3.2 Mounting the motor
SINAMICS V90, SIMOTICS S-1FL6
98 Operating Instructions, 04/2019, A5E36037884-007
3.2.2
Mounting the motor
WARNING
Personal injury and material damage due to motor falling down
Some motors, especially the 1FL609❑ are heavy. Motor falling down can cause serious
personal injury or material damage.
• The excessive weight of the motor should be considered and any necessary assistance
required for mounting should be sought.
NOTICE
Damage to the motor due to liquid entering
If the liquid enters the motor, the motor may be damaged
• During motor installation or operation, make sure that no liquid (water, oil, etc.) can
penetrate into the motor.
• When installing the motor horizontally, make sure that the cable outlet faces downward
to protect the motor from ingress of oil or water.
NOTICE
Damage to the absolute encoder due to the magnetic interference from the magnetic field
The magnetic interference from the magnetic field can cause a damage to the absolute
encoder.
• To avoid magnetic interference to the absolute encoder, keep the servo motor with an
absolute encoder at least 15 mm away from the devices that produce a magnetic field
stronger than 10 mT.
Note
Using the eyebolts
The 1FL609❑ motor (90 mm shaft he
ight) has two M8 screw holes for screwing in two
eyebolts. Lift the 1FL609❑ motor only at the eyebolts.
Eyebolts that have been screwed in must be either tightened or removed after mounting.

Siemens SINAMICS V90 Specifications

General

Power Range	0.05 kW to 7.0 kW
Protection Class	IP20
Communication	USS/Modbus RTU
Feedback	Incremental encoder
Input Voltage	1AC 200 V to 240 V, 3AC 380 V to 480 V
Control Modes	Position, Speed, Torque
Operating Temperature	0 °C to +40°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
