10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
344 Operating Instructions, 04/2019, A5E36037884-007
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p1001
Fixed speed setpoint 1
-210000.000
210000.000
0.000
rpm
Float
IM
T, U
Description:
Sets a value for the fixed speed / velocity setpoint 1.
p1002
Fixed speed setpoint 2
-210000.000
210000.000
0.000
rpm
Float
IM
T, U
Description: Sets a value for the fixed speed / velocity setpoint 2.
p1003
Fixed speed setpoint 3
-210000.000
210000.000
00.000
rpm
Float
IM
T, U
Description: Sets a value for the fixed speed / velocity setpoint 3.
p1004
Fixed speed setpoint 4
-210000.000
210000.000
0.000
rpm
Float
IM
T, U
Description: Sets a value for the fixed speed / velocity setpoint 4.
p1005
Fixed speed setpoint 5
-210000.000
210000.000
0.000
rpm
Float
IM
T, U
Description: Sets a value for the fixed speed / velocity setpoint 5.
p1006
Fixed speed setpoint 6
-210000.000
210000.000
0.000
rpm
Float
IM
T, U
Description: Sets a value for the fixed speed / velocity setpoint 6.
p1007
Fixed speed setpoint 7
-210000.000
210000.000
0.000
rpm
Float
IM
T, U
Description: Sets a value for the fixed speed / velocity setpoint 7.
p1058
Jog 1 speed setpoint
0.00
210000.000
100.00
rpm
Float
IM
T
Description:
Sets the speed/velocity for Jog 1. Jogging is level-triggered and allows the motor to be incremen-
tally moved.
Note: The parameter values displayed on the BOP are integers.
p1082 * Maximum speed 0.000 210000.000 1500.00
0
rpm Float IM T
Description: Sets the highest possible speed.
Notice: After the value has been modified, no further parameter modifications can be made.
Note:
The parameter values displayed on the BOP are integers.
The parameter applies for both motor directions.
The parameter has a limiting effect and is the reference quantity for all ramp-up and ramp-down times (e.g.
down ramps, ramp-function generator and motor potentiometer).
The range of the parameter is different when connect with different motors.
p1083 * Speed limit in positive
direction of rotation
0.000 210000.000 210000.
000
rpm Float IM T, U
Description: Sets the maximum speed for the positive direction.
Note: The parameter values displayed on the BOP are integers.
p1086 * Speed limit in negative
direction of rotation
-210000.000 0.000 -
210000.
000
rpm Float IM T, U
Description: Sets the speed limit for the negative direction.
Note: The parameter values displayed on the BOP are integers.
p1115 Ramp-function generator
selection
0 1 0 - I16 IM T
Description: Sets the ramp-function generator type.
Note: Another ramp-function generator type can only be selected when the motor is at a standstill.

Siemens SINAMICS V90 Specifications

General

Power Range	0.05 kW to 7.0 kW
Protection Class	IP20
Communication	USS/Modbus RTU
Feedback	Incremental encoder
Input Voltage	1AC 200 V to 240 V, 3AC 380 V to 480 V
Control Modes	Position, Speed, Torque
Operating Temperature	0 °C to +40°C
Storage Temperature	-40°C to +70°C
Relative Humidity	5% to 95% (non-condensing)
Altitude	Up to 1000 m above sea level
