Note
You must stop the machine before selecting an NC startup mode.
Selecting a PLC startup mode
Proceed through the following steps to select a PLC startup mode:
+
1. Select the desired operating area.
2. Press this softkey.
3. Press this softkey to open the window for selecting the PLC startup
mode.
4. Select a desired mode with the cursor keys. Two PLC startup modes
are available:
5. Use this key to select/deselect the PLC debugging.
6. Press this softkey to confirm your selection. The system then restarts
in the mode selected.
Selecting a drive startup mode
Proceed through the following steps to select an drive startup mode:
+
1. Select the desired operating area.
2. Press this softkey.
3. Press this softkey to open the window for selecting the drive startup
mode.
4. Select a desired mode with the cursor keys. Two drive startup modes
are available:
Operating in the system data management operating area
3.2 Setting startup function
Diagnostics Manual
Diagnostics Manual, 06/2015, 6FC5398-6DP10-0BA2 15
