6
"Program" Operating Area 03.04
6.10 Mana
e
ro
rams
6
Ó Siemens AG, 2004. All rights reserved
6-338 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
6.10 Manage programs
6.10.1 Overview
To allow you to handle data and programs flexibly, you can organize,
store and display them according to different criteria.
The memory is divided into:
· NC memory (main memory and program memory) containing the
active system and user programs as well as all part programs for
immediate execution and
· Hard disk drive
Programs can be exchanged with the program memory and hard disk.
Part programs may be stored either in the program memory of the NC
or on the hard disk, but they are always executed from the program
memory.
The "Load" and "Unload" functions are used to load or unload
programs to or from the program memory.
Program management
The programs and files are stored in different directories and can be
administered in the Program and Services operating areas.
The details are shown in the following overview:
Name of directories: Operating area:
· Subroutines Programs and Services
· Part programs Programs and Services
· Workpieces Programs and Services
· Definitions Services
· Comments Services
· Standard cycles Programs and Services
· Manufacturer cycles Programs and Services
· User cycles Programs and Services
