Siemens SINUMERIK 840D Diagnostics Guide

Preface 10.04
VI
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Diagnostics Guide (DA), 10.04 Edition
Hotline If you have any questions, please contact our hotline:
A&D Technical Support
Phone: +49 (0) 180 50 50 222
Fax: +49 (0) 180 50 50 223
E-mail: www.siemens.com/automation/support-request
If you have any questions about the documentation (suggestions, corrections), please fax
or e-mail us at the following addresses:
Fax: +49 (0) 9131 98 21 76
E-mail: motioncontrol.docu@siemens.com
Fax form: See the reply form at the end of the document.
Website address http://www.siemens.com/motioncontrol
SINUMERIK 840D
powerline
Since September 2001, the
• SINUMERIK 840D powerline and
• SINUMERIK 840DE powerline
have been available with improved performance. The following hardware description con-
tains a list of the available powerline modules:
References: /PHD/SINUMERIK 840D Configuration Manual
SINUMERIK 810D
powerline
Since December 2001, the
• SINUMERIK 810D powerline and
• SINUMERIK 810DE powerline
have been available with improved performance. The following hardware description con-
tains a list of the available powerline modules:
References: /PHC/SINUMERIK 810D Configuration Manual
!
Important
This document is valid for:
• SINUMERIK 840D powerline software version 7
• SINUMERIK 810D powerline software version 7
• SINUMERIK 840Di controller software version 3

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
