VII
ï›™ Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Diagnostics Guide (DA), 10.04 Edition
10.04 Preface
Export version The following functions are not available in the export version:
Sorting The alarms are sorted by ascending alarm number in each section. There are gaps in the
sequence.
Structure of
alarm description
Each alarm consists of an alarm number and alarm text. There are four description cate-
gories:
• Explanation
• Reaction
• Remedy
• Program continuation
For a more detailed explanation of the "Reaction" category, please refer to the
Section: "System reactions on alarms"
For a more detailed explanation of the "Program continuation" category, please refer to
the section: "Clear criteria for alarms"
NCK alarms Table 1_1 Alarm number ranges
Function 810E 840DE
Five axis machining package - -
Handling transformation package (five axes) - -
Multiple-axes interpolation (> 4 axes) - -
Helical interpolation 2D+6 - -
Synchronized actions, stage 2 - O1)
Measurements, stage 2 - O1)
Adaptive control - O1)
Continuous dressing - O1)
Utilization of compile cycles (OEM) - -
Multidimensional sag compensation - O1)
000 000 - 009 999 General alarms
010 000 - 019 999 Channel alarms
020 000 - 029 999 Axis/spindle alarms
030 000 - 099 999 Functional alarms
060 000 - 064 999 Cycle alarms SIEMENS
065 000 - 069 999 Cycle alarms user
070 000 - 079 999 Compile cycles, manufacturer and
OEM
