Section 2
Program jumps and deletion blocks
There is a further way of optionally including or excluding certain parts of
the program by excluding explicitly marked blocks.
The program blocks intended for optional exclusion are marked simply by
a preceding / (slash).
Example: /N200 CYCLE96(24,-30,“A“,3)
Simply by activating the option "SKP Skip block" (after pressing the VSK 4
"Prog. Cntrl." (Program control) in the automatic mode) all blocks marked
with a "/" will be ignored by the control unit.
If this option is deactivated, the marked blocks will be executed in the
same manner as all others.
Shown on the next page is a possible example for the usage of this way of
program manipulation.
SKP is activated; in the program
mode the blocks with a preceding
slash will be ignored.
SKP is deactivated; the control
also executes the blocks with a
preceding slash.
2.2 Deletion blocks
