840D/828D SINUMERIK Operate
Notes
Section 2
Operating mode “AUTO“
Display area Description (continuation)
By pressing the "Extend"-button you can switch be-
tween the normal and the extended horizontal soft-
key bar.
This symbol on the right of the dialogue line indi-
cates that more softkeys are available on the ex-
tended horizontal softkey bar.
This symbol indicates that the extended horizontal-
softkey bar is shown at the bottom of the screen.
You can switch back to the HSK 1 again by press-
ing the “Extend”-key.
By pressing the HSK 2.6 "Handwheel" the input
mask for assigning axes to all parameterized hand-
wheels is displayed.
By pressing the HSK 2.8 "Settings" a window opens
up where you can adjust the settings for manual
operation on the Sinumerik Operate.
