Tool list
3.4 Icons in the toolbar and their meaning
Icons Meaning
Red X
The tool is disabled
Yellow triangle
pointing downward
The prewarning limit has been reached
Yellow triangle
pointing upward
The tool is in a special state
Place the cursor on the marked tool. A tool
tip will provide a brief description
Green frame
The tool is preselected.
Magazine/location number:
Green double arrow
The magazine location is positioned at the
change position
Gray double arrow
The magazine location is positioned at the
loading position
Red X
The magazine location is disabled
Column header Meaning (continuation)
Drill rad.
Drill radius for
Rotary drill type 560
(Holder angle and cutting edge angle are set by de-
fault settings)
Cutting edge angle
Cuttting edge angle for turning tools
Roughing tools type 500
Finishing tools type 510
(refer to holder angle)
Loc. len
Tip length for
Roughing tools type 500
Finishing tools type 510
Plunge cutter type 520
The tip length is required for displaying the tools dur-
ing the simulation of the program processing.
Direction of spindle rotation
Turning tools and non-driven tools:
direction of the main spindle
Powered tools for milling and boring:
direction of the tool spindle
Coolant 1 and 2 can be switched off and switched on.
