840D/828D SINUMERIK Operate
Notes
Section 3
Tool list
3.5 Additional data
The following tool types require geometry data that is not included in the
tool list display.
Tool type Additional parameters
111 Conical ball
head cutter
Corner radius
121 End mill with
corner rounding
Corner radius
130 Angle head
cutter
Geometry length (length X, length Y, length Z)
Wear length (Δlength X, Δlength Y, Δlength Z)
Adapter length (length X, length Y, length Z)
131 Angle head
cutter with
corner rounding
Geometry length (length X, length Y, length Z)
Corner radius
Wear length (Δlength X, Δlength Y, Δlength Z)
Adapter length (length X, length Y, length Z)
140 Face milling
External radius
Tool angle
155 Bevel cutter
Taper angle
156 Bevel cutter
with corner
rounding
Corner radius
Taper angle
157 Conical die
milling cutter
Taper angle
Note:
You can use the configuration file to specify the data to be displayed for
specific tool types in the "Additional Data" window.
The VSK “Further data” is only available for those tool types which will sup-
port this function .
