840D/828D SINUMERIK Operate
Notes
Section 8
User variables
8.4.1 Displaying and editing global GUD
1. Press the “MENU SELECT“-key on the operator
panel, then the HSK 2 “Parameter” to open the oper-
ating area “Parameter”. Alternatively press the
“OFFSET”-key on the keyboard.
2. Press the HSK 5 “User variable“.
3. Press the VSK 1.2 “Global GUD“.
4. The “Global user variables” window opens. A list of
the defined “SGUD” variables respectively the data
selected by VSK 6 “GUD selection” are displayed.
OR -
4. By pressing the VSK 6 "GUD selection" further GUD
data are available.
Please refer to the manufacturer`s manual.
