840D/828D SINUMERIK Operate
Notes
Section 2
Basics
2.3 Standard commands in the G code Editor
Unlike in a program with ShopTurn functionality the following G-code com-
mands are programmed through graphically supported parameter masks,
where as in the programGUIDE G-code editor they have to be specifically
typed into the editor.
Note:
Unnamed G commands are freely selectable.
Command Meaning
G 00 Rapid traverse command
G 01 Linear interpolation (Feed motion)
G 02 Circular interpolation anti-clockwise
G 03 Circular interpolation clockwise
G 04 Dwell - Hint: Additional parameter inputs are required
G 17 Plane selection XY Z
G 18 Plane selection ZX Y
G 19 Plane selection YZ X
G 54 - G 57 Selection of the zero points
Note:
More zero points may be available.
The documentation by the machine manufacturer must be
observed.
G 90 Absolute dimensions
G 91 Incremental dimensions
The following standard M commands are available in the G code editor.
Note: Unnamed M-commands are freely selectable. The documentation by
the machine manufacturer must be observed.
Command Meaning
M00 Programmed Halt
M01 Optional stop, see also M00
M02 End of Program
M03 Spindle Start clockwise
M04 Spindle Start anti-clockwise
M05 Spindle Stop
M06 Tool change
M08 Coolant ON
M09 Coolant OFF
M19 Defined spindle stop
M30 End of Program (see also M02)
