B605
B605 Page 8 840D/828D SINUMERIK Operate
Notes
Section 2
Basics
2.4 Navigation in the editor window
For a fast and comfortable navigation within a G code program and the
parameter masks you can use the blue cursor keys.
With the blue “cursor-up”-key on the keyboard you
can navigate upwards in the program editor and the
parameter masks.
With the blue “cursor-down”-key on the keyboard
you can navigate downwards in the program editor
and the parameter masks.
The arrow symbol (extend symbol) on the right side
of a cycle or workpiece line in the editor window
indicates that you can enter the parameter input
mask by pressing the “cursor-to-the-right”-key
The “cursor-to-the-right”-key opens the parameter
mask of the corresponding program block.
The “cursor-to-the-left”-key closes the parameter
mask for the cycle or workpiece settings and brings
you back to the editor window, displaying the G
code program.
The following standard “other“ commands are available in the G code edi-
tor.
Note:
The documentation by the machine manufacturer must be observed.
Command Meaning
T
Tool call-up (Tool)
S
Speed (Speed)
F
Feed rate (Feed)
