840D/828D SINUMERIK Operate
Notes
Section 2
Simple programming example
2.1 Creating a new programGUIDE program
A new G code program can be created from all operating modes, as fol-
lows:
1. Press the “Program Manager”-key on the keyboard.
The program manager will be opened directly.
- OR -
1. Press the “MENU SELECT”-key on the operator
panel.
Press the yellow HSK 1.4 “Program Manager”.
The program manager opens.
2. Select a drive where you want to create the program
(“NC”, “Local drive”, “USB”), by pressing a horizontal
softkey.
3. Press the VSK 2 “New“.
The vertical softkey bar with functions for creating
new programs opens.
4. Press the VSK 4 „programGUIDE G code“ to open
the input mask for creating a new G code program.
Select “Main program MPF”.
5. Enter a name for the program in the “Name” field,
e.g DIN_DRILLING_1.MPF and accept with press-
ing the VSK 8 “OK”.
The editor window for entering G code commands
opens.
Description:
A simple drilling machining is to be programmed with the programGUIDE
in ShopTurn.
Aim:
A new G code program is to be created and opened.
The G code lines and the drill cycle must be programmed and the program
is to be simulated.
For this, the data below are to be used:
Tool data:
Drill Ø 8,5 mm (DRILL_D8.5)
Technology data:
F 150 mm/min
S 1000 rpm
