840D/828D SINUMERIK Operate Page 7
B504
B504
Notes
P1 M1 P2 P3 P4 M2
X
25 35 27,929 37,071 40 30
Z
-20 -20 -23,536 -28,107 -31,642 -31,642
For the solution method see the next page.
5.2 Solution for the exemplary functions
Section 5
Exemplary functions
