Parameter Description Unit
V3
(only for stock re‐
moval and "man‐
ual" clearance dis‐
tance)
Clearance distance mm
DTB -
(only G code)
● Dwell time at drilling depth in seconds
● Dwell time at drilling depth in revolutions
s
rev
DT
● Dwell time at final drilling depth in seconds
● Dwell time at final drilling depth in revolutions
s
rev
DTS - (only for
stock removal)
(only G code)
● Dwell time for swarf removal in seconds
● Dwell time for swarf removal in revolutions
s
rev
Parameters in the "Input simple" mode
G code program parameters ShopMill program parameters
Input
● simple
RP Retraction plane mm T Tool name
D Cutting edge number
F Feedrate mm/min
mm/rev
S / V Spindle speed or constant
cutting rate
rpm
m/min
Parameter Description
Machining
position
● Single position
Drill hole at programmed position.
● Position pattern
Position with MCALL
Machining
● Swarf removal
The drill is retracted from the workpiece for swarf removal.
● Chip breaking
The drill is retracted by the retraction distance V2 for chip breaking.
Z0 (only for G code) Reference point Z mm
Z1 Drilling depth (abs) or drilling depth in relation to Z0 (inc)
It is inserted into the workpiece until it reaches Z1.
D - (only for G code) First drilling depth (abs) or first drilling depth in relation to Z0 (inc) mm
D - (only for Shop‐
Mill)
Maximum depth infeed mm
Programming technological functions (cycles)
10.1 Drilling
Milling
382 Operating Manual, 08/2018, 6FC5398-7CP41-0BA0
