3.3 Type plate
NCU 7x0.2
Manual, 02/2011, 6FC5397-0AP20-0BA0
23
3.3 Type plate
Side-mounted type plate
The following figure shows you all the information included on the type plate located on the
side of the unit.
2UGHUQXPEHU
6HULDOQXPEHU
,'QXPEHU
+:YHUVLRQ
&RPSRQHQWQDPH
Figure 3-3 Type plate
You might need to access the information provided on the side-mounted type plate after the
equipment has been mounted. Since the type plate is located on the right-hand side of the
housing, which is the side typically used to connect to the SINAMICS S120 module, we
recommend that you make a note of the serial number of the control unit prior to assembly.
Note
The information contained in each field of the type plate on the current control unit may differ
from the information presented in this manual (for example, a later product version,
approvals and marks that have not yet been issued, etc., may be shown).
