Dimension drawings
4






Figure4-1 Front, rear and side view of MCP 2400 (all speci󹪝cations in mm)
The installation clearance for the MCP is 55mm.
ONE MCP Part 2: MCP 2400
Equipment Manual, 08/2023, A5E50324707B AB 17
