Siemens SIPROTEC 5 Technical Data

Statistical Values of the Circuit Breaker
Op.cnt. (operation counter)
Range 0 to 999999999
Tolerance None
∑I Off (sum of the primary currents switched off) A, kA, MA, GA, TA, PA primary
Range 0 to 9.2e+15
Operating hours h
Range 0 to 9999999 h
Tolerance 1 h
Circuit breaker open hours h
Range 0 to 9999999 h
Tolerance 1 h
Statistical Values of the Disconnector
Op.cnt. (operation counter)
Range 0 to 999999999
Tolerance None
Technical Data
11.47 Operational Measured Values and Statistical Values
SIPROTEC 5, High-Voltage Bay Controller, Manual 1219
C53000-G5040-C015-A, Edition 05.2018

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
