Siemens SIPROTEC 5 Technical Data

Energy Values
Setting Values
Active energy W
p
kWh, MWh, GWh
Measuring range
Voltage range
Current range
Frequency range
|cosφ| ≥ 0.01
(0.8 to 1.2) · V
rated
(0.1 to 2) · I
rated
49 Hz to 51 Hz at f
rated
= 50 Hz
59 Hz to 61 Hz at f
rated
= 60 Hz
Tolerance 0.3 % of the measured value in the above mentioned measuring
range
Frequency range (expanded) 40 Hz to 69 Hz at f
rated
= 50 Hz
50 Hz to 70 Hz at f
rted
= 60 Hz
Tolerance 0.5 % of the measured value in the above mentioned measuring
range
Reactive energy W
q
kvarh, Mvarh, Gvarh
Measuring range
Voltage range
Current range
Frequency range
|cosφ| ≤ 0,984
(0.8 to 1.2) · V
rated
(0.1 to 2) · I
rated
49 Hz to 51 Hz at f
rated
= 50 Hz
59 Hz to 61 Hz at f
rated
= 60 Hz
Tolerance 1.0 % of the measured value in the above mentioned measuring
range
Frequency range (expanded) 40 Hz to 69 Hz at f
rated
= 50 Hz
50 Hz to 70 Hz at f
rated
= 60 Hz
Tolerance 1.5 % of the measured value in the above mentioned measuring
range
11.48
Technical Data
11.48 Energy Values
1220 SIPROTEC 5, High-Voltage Bay Controller, Manual
C53000-G5040-C015-A, Edition 05.2018

Siemens SIPROTEC 5 Specifications

General

Series	SIPROTEC 5
Communication Protocols	IEC 61850, DNP3, Modbus
Cybersecurity	Role-based access control, secure communication
Modular Design	Yes
Hardware Redundancy	Optional
Operating Temperature	-25°C to +70°C
Digital Inputs	Configurable, number depends on I/O modules
Digital Outputs	Configurable, number depends on I/O modules
Analog Inputs	Configurable, number depends on I/O modules
Current Transformer Inputs	Configurable, number depends on I/O modules
Voltage Transformer Inputs	Configurable, number depends on I/O modules
Time Synchronization	IRIG-B, SNTP, PTP
Protection Functions	Overcurrent, Differential, Distance, Over/Under Voltage, Frequency
Housing	19-inch Rack Mount
Dimensions	Depends on module configuration
Weight	Depends on module configuration
Voltage Input	24V DC, 48V DC, 110V DC, 125V DC, 220V DC, 250V DC
