Page #38 background image
7SJ46 Handbuch Technische Daten
C53000-K1174-C002-4 38
Ansprechzeiten
Rückfallverhältnis
Toleranzen
UMZ (DT O/ C 50/ 51)
AMZ (IEC 51 bzw. ANSI 51)
Abweichung des Messwertes durch versch. Einflussgrößen
Gesamtgerät ca. 38 ms
Rückfallverhältnis ca. 0,95 bei UMZ (DT O/C 50/51)
ca.0,91beiAMZ(IEC51bzw.ANSI51)
Stromanregungen I>, I>>, IE> 5 % vom Einstellwert, bzw. 5 % vom Nenn-
wert (bei Schwellen < I
N
)
Verzögerungszeiten T 1 % bzw. 30 ms
Anregeschwellen 5 % vom Einstellwert, bzw. 5 % vom Nenn-
wert (bei Schwellen < I
N
)
Zeitablauf für 2 I/I
P
20 5 % bzw. 50 ms
Frequenz im Bereich
0,95 < f/f
N
<1,05: <2,5%
Frequenz im Bereich
0,9 < f/f
N
<1,1: <10%
Oberschwingungen:
bis 10% 3. und 5. Harmonische:
<1%
Gleichanteile: < 5%
Hilfsgleichspg. im Bereich
0,8 U
H
/U
HN
1,2
Hilfswechselspg. im Bereich
0,8 U
H
/U
HN
1,15
<1%
<1%
Temperatur im Bereich
5°C bis +70°C < 0,5 % / 10 K
