Manual 7SJ46 Technical Data
C53000-K1174-C002-4 63
2.11 Technical Data
General device data
Current inputs
Power supply
Output relays
UL-Listing for relay output with the following rated data:
120 Vac Pilot duty, B300
240 Vac Pilot duty, B300
240 Vac 5 A General Purpose
24 Vdc 5 A General Purpose
48 Vdc 0.8 A General Purpose
240 Vdc 0.1 A General Purpose
120Vac 1/6hp(4.4FLA)
240Vac 1/2hp(4.9FLA)
Rated frequency f
N
50 Hz or 60 Hz (adjustable)
Rated current, normal earth
current I
N
1Aor5A
Power consumption
–atI
N
= 1 A approx. 0.01 VA at I
N
–atI
N
= 5 A approx. 0.2 VA at I
N
Rating of current transformer circuit
– thermal (rms) 100·I
N
for 1 s
30·I
N
for 10 s
4·I
N
continuous
– dynamic (peak value) 250·I
N
for one half-cycle
Input voltage range 24 V DC to 250 V DC (+/- 20%)
60 V AC to 230 V AC (–20%, +15%)
Power consumption approx. 1,5 W DC
approx. 3 VA AC at U
H
= 110 V
approx. 5.5 VA AC at U
H
=230V
Number 2 (NO contacts), 1 live status contact
Switching capability MAKE 1000 W/VA
BREAK 30 VA
40 W resistive load
25 VA at L/R ≤ 50 ms
Switching voltage ≤ 250 V DC,
≤ 240 V AC
Permissible current per contact 5 A continuous;
30 A for 0.5 s (inrush current)
