Manual 7SJ46 Construction
C53000-K1174-C002-4 47
Figure 2-2 Device fronts of the available device variants
On the back of the device (Figure 2-3), the terminal blocks with
the screw terminals are located:
Rear view
Figure 2-3 Terminal blocks on the rear of the 7SJ46
The nameplate sticker, showing important information such as
power supply rating, nominal current rating and ordering number
(MLFB), is located on the side of the housing.
ANSI
IEC
phase
earth
phase
earth
