Technical Data
Load Capability of the Voltage Divider
Terminals 1B – 4B
Max. permissible continuous voltage 55 V AC
Continuous output power 2 W
Max. permissible voltage (60 s) 550 V AC
Max. dissipated power 185 W (max. 60 s, recovery time 600 s)
NOTE
The minimum load of 200 kΩ (protection relay input impedance) is needed to reach the necessary accu-
racy.
Weight
The weight of the device is 1.9 kg (4.2 lb.).
3.4
3.4.1
3.4.2
7XR86 Voltage Divider (5:1, 5:2)
3.4 Technical Data
SIPROTEC, Coupling Units for Generator Protection, Manual 41
C53000-H5040-C072-1, Edition 09.2018
