Display overview
LED displays on 3RW40 Auxiliary contacts
Soft starter Motor protection
3RW40
DEVICE
(rd/gn/ylw)
STATE /
BYPASSED
/ FAILURE
(gn/rd)
OVERLOAD
(rd)
RESET
MODE
(ylw/gn)
13 14
(ON)
13 14
(RUN)
24 23
(BYPASSED)
96 95 98
FAILURE /
OVERLOAD
U
s
= 0
Operating state
IN
OFF
0
Start-up
1
Bypassed
1
Run-out
0
Warning
I
e
/ class setting invalid
Start-up locked, device too warm
Error
Supply voltage electronics invalid
Invalid I
e
/ class setting and IN (0 -> 1)
Motor protection switch-off
Overload relay / thermistor
Thermistor motor protection
Wire break / short circuit
Thermal overload device
- Missing load voltage
- Phase failure, no load
Device fault
Test function
1)
Press TEST for t > 5 s
RESET MODE (press to change)
Manual Reset
Auto Reset
Remote Reset see Fig. 6.2
LED display
1)
Motor protection shutdown test
gn
=
ylw
=
rd
=
OFF ON flashing flickering green yellow red
WARNING
Automatic restart.
May result in death, serious injury or damage to property.
The automatic reset mode (RESET MODE) must not be used in applications where an unexpected restart of the motor after the
recovery time has elapsed may lead to personal injury or damage to property.
The start command (e.g. by the PLC) must be reset before a reset command, since an automatic restart is executed when a start
command is pending after the reset command. This especially applies to motor protection tripping. For safety reasons it is
recommended to integrate the group fault output (terminals 95 and 96) into the control.
gn
gn
gn
gn
gn
gn
gn
gn
gn gn
ylw
rd
gn
rd
gn
gn
ylw
rd
gn
rd
rd
rd
gn
rd
ylw
gn
!

Siemens SIRIUS 3RW40 24 Series Specifications

General

Number of poles	3
Soft starter type	Solid-state
Integrated bypass contact system	Yes
Insulation voltage rated value	690 V
Adjustable motor current	Yes
Type of voltage of the control supply voltage	AC/DC
Relative negative tolerance of the control supply voltage at AC at 50 Hz	-15 %
Relative negative tolerance of the control supply voltage at AC at 60 Hz	-15 %
Number of CO contacts for signaling	0
Installation altitude at height above sea level maximum	2000 m
Height	170 mm
Degree of protection	IP20
Control voltage	24 V DC
Product brand name	Siemens
Product function	Overload protection
Reference identifier acc. to DIN EN 81346-2	K
Reference identifier acc. to DIN EN 61346-2	K
Operating frequency rated value	50 ... 60 Hz
Relative positive tolerance of the control supply voltage at AC at 50 Hz	10 %
Relative positive tolerance of the control supply voltage at AC at 60 Hz	10 %
Ambient temperature during operation	-20°C to +60°C
