Selection tables 400 V AC
3.6 Motor starter protector + solid-state reversing contactor
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
43
Standard
three-phase motor
4-pole at
400 V AC
1)
Solid-state reversing contactor
2)
Standard
output
P
Motor
current
(guide
value)
I
Setting range
Overload
release
Motor starter
protector
Motor starter
protector
Size
Mounting with
lateral clearance of
20 mm
Butt-mounting
3)
kW A A Order No. Order No. Order No.
Short-circuit breaking capacity I
q
= 10 kA
2,2 5 4,50 ... 6,30 3RV2011-1GA10 S00 3RF3405-1BD04
3 6,5 5,50 ... 8,00 3RV2011-1HA10 S00 3RF3410-1BD04
3RF3410-1BD04
Order numbers for basic versions with screw terminals and spring-loaded terminals also possible. 3RA2921-1BA00 link
module can only be used with screw terminals.
1)
Guide value for 4-pole standard motors at 400 V AC, 50 Hz. Selection depends on the concrete startup and rated data
of the protected motor.
2)
Rated currents taken into account at 40 °C ambient temperature. Rated control supply voltage 230 V AC, 50 Hz. Other
control voltages are also possible.
3) The rated currents must be reduced if the solid-state contactor is butt mounted. Detailed characteristic curves can be
found in Chapter 3 of the SIRIUS Innovations System Manual.
See also
Industrial Controls System Manual - SIRIUS Innovations
(http://support.automation.siemens.com
/WW/view/en/39740306)
