Siemens SIRIUS - Motor Starter Protector + Contactor Assembly for Star-Delta Start + 3 RB22; 23; 3 Solid-State Overload Relay, or 3 UF7

Selection tables 400 V AC
3.8 Motor starter protector + contactor assembly for star-delta start + 3RB22 / 23 / 3 solid-state overload relay, or 3UF7
Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
45
3.8 Motor starter protector + contactor assembly for star-delta start +
3RB22 / 23 / 3 solid-state overload relay, or 3UF7
CLASS 10, types of coordination 1 and 2,
short-circuit breaking capacity
I
q
= 150 kA
M
$&9
Standard three-
phase motor
4-pole at
400 V AC
1)
Contactors
2)
Stan-
dard
output
P
Motor
current
I
Motor
starter
protector
Line contactor +
delta contactor
Star contactor
Overload relay (solid-
state) or current
measuring module
3)
Setting
range
Overload
release
Overload
relay
kW A Order No. Order No. Order No.
Size
Order No. A
Type of coordination 1
5,5 11,5 3RV2311-
4AC10
3RT2016-1AP01 3RT2015-1AP01 S00/S00/S00 3RB3026-1QB0 6 ... 25
5,5 11,5 3RV2321-
4AC10
3RT2016-1AP01 3RT2015-1AP01 S0/S00/S00 3RB3026-1QB0 6 ... 25
5,5 11,5 3RV2321-
4AC10
3RT2024-1AP00 3RT2024-1AP00 S0/S0/S0 3RB3026-1QB0 6 ... 25
7,5 15,5 3RV2321-
4BC10
3RT2025-1AP00 3RT2024-1AP00 S0/S0/S0 3RB3026-1QB0 6 ... 25
11 22 3RV2321-
4EC10
3RT2025-1AP00 3RT2024-1AP00 S0/S0/S0 3RB3026-1VB0 10 ... 40
Type of coordination 1 with 3UF7 / 3RB3
5,5 11,5 3RV2311-
4AC10
3RT2016-1AP01 3RT2015-1AP01 S00/S00/S00 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
5,5 11,5 3RV2321-
4AC10
3RT2016-1AP01 3RT2015-1AP01 S0/S00/S00 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
5,5 11,5 3RV2321-
4AC10
3RT2024-1AP00 3RT2024-1AP00 S0/S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
7,5 15,5 3RV2321-
4CC10
3RT2025-1AP00 3RT2024-1AP00 S0/S0/S0 3UF7101-1AA00-0/
3RB2906-2DG1
2,4 ... 25
11 22 3RV2321-
4EC10
3RT2025-1AP00 3RT2024-1AP00 S0/S0/S0 3UF7102-1AA00-0/
3RB2906-2JG1
10 ... 100
