Siemens SIRIUS Configuration Manual

Selection tables 400 V AC
3.5 Motor starter protector + solid-state contactor
Configuring SIRIUS Innovations
40 Configuration Manual, 04/2010, A8E56203880102-02
3.5 Motor starter protector + solid-state contactor
CLASS 10, type of coordination 1,
short-circuit breaking capacity
I
q
≥ 5 kA / 50 kA
NSB0_01948
$
&9
Standard
three-phase motor
4-pole at
400 V AC
1)
Solid-state contactor
2)
Stan-
dard
output
P
Motor
current
(guide
value)
I
Setting range
Overload release
Motor starter
protector
Motor starter
protector
Mounting with lateral
clearance of 20 mm
Butt-mounting
3)
kW A A Order No.
Size
Order No. Order No.
Short-circuit breaking capacity I
q
= 50 kA
0,06 0,2 0,14 ... 0,20 3RV2011-0BA10 S00
0,06 0,2 0,18 ... 0,25 3RV2011-0CA10 S00
0,09 0,3 0,22 ... 0,32 3RV2011-0DA10 S00
0,09 0,3 0,28 ... 0,40 3RV2011-0EA10 S00
0,12 0,4 0,35 ... 0,50 3RV2011-0FA10 S00
0,18 0,6 0,45 ... 0,63 3RV2011-0GA10 S00
0,25 0,85 0,55 ... 0,80 3RV2011-0HA10 S00
0,25 0,85 0,70 ... 1,00 3RV2011-0JA10 S00
0,37 1,1 0,90 ... 1,25 3RV2011-0KA10 S00
0,55 1,5 1,10 ... 1,60 3RV2011-1AA10 S00
0,75 1,9 1,40 ... 2,00 3RV2011-1BA10 S00
0,75 1,9 1,80 ... 2,50 3RV2011-1CA10 S00
1,1 2,7 2,20 ... 3,20 3RV2011-1DA10 S00
1,5 3,6 2,80 ... 4,00 3RV2011-1EA10 S00
1,5 3,6 3,50 ... 5,00 3RV2011-1FA10 S00
2,2 5 4,50 ... 6,30 3RV2011-1GA10 S00
3RF3405-1BB04 3RF3405-1BB04
