Siemens SIRIUS - 5 Fused Selection Tables up to 690 V; Contactor Short-Circuit Protection

Configuring SIRIUS Innovations
Configuration Manual, 04/2010, A8E56203880102-02
71
Fused selection tables up to 690 V
5
5.1 Contactor short-circuit protection
Short-circuit protection up to 100 kA
Type of coordination 1 and 2
Table 5- 1 Fuse links according to IEC 60947 operating class gG,
(NH DIAZED, NEOZED; type 3NA, 5SB, 5SE)
Contactor Fuse links
1)
MLFB P [kW] Type of coordination 1
2)
Type of coordination 2
2)
Size S00
3RT2015-1.. 3 35 20
3RT2016-1.. 4 35 20
3RT2017-1.. 5,5 35 20
3RT2018-1.. 7,5 50 25
Size S0
3RT2024-1.. 5,5 63 25
3RT2025-1.. 7,5 63 25
3RT2026-1.. 11 100 35
3RT2027-1.. 15 125 50
3RT2028-1.. 18,5 125 50
1)
Please take account of the operating voltage
2)
Assignment and short-circuit protective devices acc. to DIN EN 60947-4-1
