Siemens SIRIUS Configuration Manual

Selection tables 500 V AC
4.3 Motor starter protector + contactor + 3RB3 solid-state overload relay
Configuring SIRIUS Innovations
60 Configuration Manual, 04/2010, A8E56203880102-02
Standard three-
phase motor
4-pole at
400 V AC
1)
Stan-
dard
output
P
Motor
current
I
Motor starter
protector
Starter protection
3)
Contactor
2)
Overload relay
(solid-state)
Setting range
Overload
release
Overload
relay
kW A
Setting
range
Overload
release
Motor
starter
protector
Order No. Order No.
Size
Order No. A
CLASS 20
0,04 0,11 0,32 3RV2311-0DC10 3RT2015-1AP01 S00/S00/S00 3RB3016-2RB0 0,1 ... 0,40
0,06 0,16 0,32 3RV2311-0DC10 3RT2015-1AP01 S00/S00/S00 3RB3016-2RB0 0,1 ... 0,40
0,09 0,24 0,5 ... 0,63 3RV2011-0GA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2RB0 0,1 ... 0,40
0,12 0,32 0,6 ... 0,8 3RV2011-0HA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2NB0 0,3 ... 1,25
0,18 0,48 0,9 ... 1,25 3RV2011-0KA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2NB0 0,3 ... 1,25
0,25 0,68 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2NB0 0,3 ... 1,25
0,37 0,88 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2NB0 0,3 ... 1,25
0,55 1,20 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2PB0 1,0 ... 4,00
0,75 1,50 2,2 ... 3,2 3RV2011-1DA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2PB0 1,0 ... 4,00
1,1 2,20 3,5 ... 5 3RV2011-1FA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2PB0 1,0 ... 4,00
1,5 2,90 4,5 ... 6,3 3RV2011-1GA10 3RT2015-1AP01 S00/S00/S00 3RB3016-2PB0 1,0 ... 4,00
2,2 3,90 7,0 ... 10 3RV2011-1JA10 3RT2017-1AP01 S00/S00/S00 3RB3016-2SB0 3,0 ... 12,00
3 5,20 9,0 ... 12,5 3RV2011-1KA10 3RT2018-1AP01 S00/S00/S00 3RB3016-2SB0 3,0 ... 12,00
4 6,80 11,0 ... 16 3RV2011-4AA10 3RT2018-1AP01 S00/S00/S00 3RB3016-2SB0 3,0 ... 12,00
5,5 9,20 14,0 ... 20 3RV2021-4BA10 3RT2026-1AP00 S0/S0/S0 3RB3026-2QB0 6,0 ... 25,00
7,5 12,40 20,0 ... 25 3RV2021-4DA10 3RT2027-1AP00 S0/S0/S0 3RB3026-2QB0 6,0 ... 25,00
CLASS 30
0,04 0,11 0,32 3RV2311-0DC10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,40
0,06 0,16 0,4 ... 0,5 3RV2011-0FA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,40
0,09 0,24 0,6 ... 0,8 3RV2011-0HA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4RB0 0,1 ... 0,40
0,12 0,32 0,9 ... 1,25 3RV2011-0KA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,18 0,48 1,1 ... 1,6 3RV2011-1AA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,25 0,68 1,4 ... 2 3RV2011-1BA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,37 0,88 1,8 ... 2,5 3RV2011-1CA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4NB0 0,3 ... 1,25
0,55 1,20 2,8 ... 4 3RV2011-1EA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4PB0 1,0 ... 4,00
0,75 1,50 3,5 ... 5 3RV2011-1FA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4PB0 1,0 ... 4,00
1,1 2,20 4,5 ... 6,3 3RV2011-1GA10 3RT2015-1AP01 S00/S00/S00 3RB3113-4PB0 1,0 ... 4,00
1,5 2,90 7,0 ... 10 3RV2011-1JA10 3RT2017-1AP01 S00/S00/S00 3RB3113-4PB0 1,0 ... 4,00
2,2 3,90 9,0 ... 12,5 3RV2011-1KA10 3RT2018-1AP01 S00/S00/S00 3RB3113-4RB0 3,0 ... 12,00
Order numbers for basic versions with screw terminals and spring-loaded terminals also possible.
1)
Guide value for 4-pole standard motors at 500 V AC, 50 Hz. Selection depends on the concrete startup and rated data
of the protected motor.
2)
Rated control supply voltage 230 V AC, 50 Hz, other control voltages possible. 3RA2921-1BA00 link module can only
be used with screw terminals.
3)
The motor starter protector is to be set to maximum current value.

Siemens SIRIUS Specifications

General

Product brand name	Siemens
Series	SIRIUS
Coil Voltage	24V DC, 110V AC, 230V AC
Switching Capacity	Up to 10A
Mounting Type	DIN rail
Product designation	SIRIUS
Contact Material	Silver alloy
Contact Rating	Varies depending on the specific SIRIUS relay model (e.g., 6 A at 250 V AC, 10 A at 250 V AC)
Switching Voltage	Varies depending on the specific SIRIUS relay model (e.g., 250 V AC, 400 V AC)
Mechanical Life	Up to 10 million operations
Electrical Life	Up to 100, 000 operations
Operating Temperature	-25°C to +55°C
Protection Class	IP20
Size of relay base	Varies depending on the specific SIRIUS relay model
