Applications
9.6 Protecting against longer power failures
SITOP PSU100S
66 Operating Instructions, 02.2013, C98130-A7589-A1-3-7629
9.6 Protecting against longer power failures
Sudden and longer failures of the line supply voltage can result in undefined states and
significant danger as a result of the associated failure of the plant or system control. The
SITOP power supply product portfolio includes various DC-UPS solutions to prevent the
failure of the 24 V power supply voltage.
Power supply failures up into the minutes range can be buffered using the maintenance-free
SITOP UPS500 DC-UPS modules based on capacitors (Figure 9-6 24 V buffering to allow
the sa
ving of process data and controlled shutdown of PCs (Page 66)).
3RZHUVXSSO\
9'&EXIIHUHG
,QGXVWULDO3&
9'&XQEXIIHUHG
$FWXDWRUV
HJPRWRU
FRQWUROVDQG
YDOYHV
+0,
'LVWULEXWHG,2ZLWK
VHQVRUV
,QGLFDWRU
OLJKW
6,723
8366
6,723
8366
Figure 9-6 24 V buffering to allow the saving of process data and controlled shutdown of PCs
