Siemens SQL36E series User Manual

10/12
Building Technologies Electromotoric Actuators CA1N4505en
HVAC Products 26.10.2006
4505A02
(Y1)
(G)
(G0)
G
Y2Y1
(Y2)
N2
Q1 Q2
Y2
(Y1)
(G)
(G0)
SP
SN
AC 24 V
G
Y2Y1
(Y2)
N1
Q1 Q2
Y1
N1, N2 Controller
Y1, Y2 Actuator
SP System potential AC 24 V
SN System neutral
Q1, Q2 Controller contacts
Dimensions
Dimensions in mm
* Mounting height of actuator including ASK35... mounting kit = 168 mm
> 100 mm: Minimum clearance from wall or ceiling
> 200 mm: For mounting, connection, operation, service, etc.
SQL85.00
SQL35.00
SQL85.00
