Siemens SQL36E series User Manual

11/12
Building Technologies Electromotoric Actuators CA1N4505en
HVAC Products 26.10.2006
[mm]
XX
G
Z
Y
B
L I
D
H
C
K J
M
E
A
4505M03
G
Z
Y
B
L I
D
H
C
K J
M
E
A
SQL36E50F04 SQL36E50F05
DN 40…65 80…125
A 210
B 73
C 137
D 210
E 65
G Ø 80
H 42
I 126
J 149
K 110
L 259
M 124
X ¨ 11 ¨ 14
Y 42
Z 50
EN 5211 F04 F05
kg
4.5 kg
> 100 mm: Minimum clearance from wall or ceiling
> 200 mm: For mounting, connection, operation, service, etc.
SQL36E50F04
SQL36E50F05
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
..
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
