Siemens SQM40 Series User Manual

10/26
Building Technologies Division CC1N7817en
24.02.2015
Type summary (cont´d) (other types on request) (cont’d)

Note
Not all types of actuators are available ex stock. Additional versions are available on
request.
Type of drive shaft
Max.
torque
Shaft
no.
 10 mm, woodruff key as per DIN 6888
10 Nm 1
 9.5 mm, square shaft
15 Nm 4
 10 mm D type shaft, compatible with SQM45...
10 Nm 5
 14 mm with parallel key as per DIN 6885, compatible with SQM48...
20 Nm 7
Drive shafts:
